ASRock Z77 Extreme9 Motherboard Installation Guide
This guide introduces the ASRock Z77 Extreme9 motherboard, an ATX‑form factor board supporting 2nd and 3rd‑generation Intel Core i7/i5/i3 CPUs in an LGA1155 socket. It outlines the package contents, key specifications such as memory capacity, expansion slots, and integrated Wi‑Fi/BT module, and directs users to the full user manual for detailed BIOS configuration.
The document includes a layout diagram of the motherboard, I/O panel descriptions, and a brief description of the Wi‑Fi + BT module and ASRock Wi‑SB Box. It also provides quick steps for installing drivers and applying Windows hot‑fixes after the hardware is assembled.
| Form Factor | ATX (12.0‑in x 9.6‑in) |
|---|---|
| CPU Support | 2nd/3rd‑Gen Intel Core i7/i5/i3, LGA1155 |
| Memory Slots | 4 x DDR3 DIMM slots |
| Maximum Memory Capacity | 32 GB |
| Chipset | Intel® Z77 |
It supports 2nd‑ and 3rd‑generation Intel Core i7, i5, and i3 processors using the LGA1155 socket.
