The document describes the features and characteristics of ROHM's Thick Film Chip Resistors MCR Series, including a full lineup of products ranging from ultra small size (01005) to 2512 with jumper type, high reliability metal glazed thick film, ISO9001/ISO/TS16949 certification, and AEC-Q200 compliant automotive products.
The MCR series from ROHM provides a full line of general‑purpose thick‑film chip resistors ranging from ultra‑small 01005 size to 2512, including jumper types. The resistors are ISO‑9001/TS‑16949 certified and the automotive versions meet AEC‑Q200 compliance.
The sheet lists part numbers, size dimensions, resistance ranges, tolerances, power derating curves, insulation resistance, failure rates and mechanical data such as weight and reel dimensions. It also includes handling guidelines for soldering and environmental testing.
| Resistance range | 102 Ω to 3 MΩ |
|---|---|
| Insulation resistance | 1000 MΩ |
| Failure rate | 0.0038 FIT (MCR004) |
| Weight (MCR004) | 0.04 mg |
| Operating temperature range | -55 °C to +125 °C |
| Derating temperature | Power must be derated above 70 °C |
| Soldering temperature | 235 °C – 245 °C |
Yes, the automotive version of the MCR series is AEC‑Q200 compliant.
The insulation resistance is specified as 1000 MΩ.
A soldering temperature of 235 °C to 245 °C is recommended.
