MC 1,5/ 5-ST-3,5 is a connector produced by Phoenix Contact. The rated current is 8A, the rated voltage is 160V, the pin spacing is 3.5mm, the number of pins is 5, and the connector type is screw connector.
The MC 1,5/5-ST-3,5 is a screw‑connection terminal block with a nominal current of 8 A and a rated voltage of 160 V. It features a 3.5 mm pitch, five positions, and compact dimensions (height 11.4 mm, width 14 mm). The unit is supplied in packs of 50 and includes standard markings and certifications.
The handbook lists compatible accessories such as cable housings, marker cards and a screwdriver, and provides part numbers for related headers and additional products. Contact information for Phoenix Contact and drawing references are also included.
| Nominal current | 8 A |
|---|---|
| Rated voltage | 160 V |
| Pitch | 3.5 mm |
| Number of positions | 5 |
| Height | 11.4 mm |
| Width (dimension a) | 14 mm |
| Screw thread | M2 |
| Tightening torque | 0.22 Nm |
The terminal block is rated for a nominal current of 8 A.
The pitch of the terminal block is 3.5 mm.
It has five positions.
A tightening torque of 0.22 Nm is recommended.
