The SMKDSN 1,5/6-5,08 is a 6‑position screw‑connection terminal block with a 5.08 mm pitch, designed for use in industrial control panels. It supports a nominal current of 13.5 A and a nominal voltage of 250 V, and is supplied in packs of 50 pieces.
Key technical data include dimensions (12 mm length, 5.08 mm pitch), weight (0.00682 kg per piece), and certifications such as UL, CSA, CUL, and GOST. The product complies with RoHS/WEEE regulations since 2003 and is available through the Phoenix Contact online catalog.
| Nominal current | 13.5 A |
|---|---|
| Nominal voltage | 250 V |
| Pitch | 5.08 mm |
| Number of positions | 6 |
| Length | 12 mm |
| Weight per piece | 0.00682 kg |
| Certifications | UL, CSA, CUL, GOST, SEV |
The terminal block is rated for a nominal current of 13.5 A.
It has six positions.
The pitch is 5.08 mm.
More information is available on the Phoenix Contact website and e‑shop.
