TEMD1000 series are PIN photodiodes with high speed and high radiant sensitivity in black, surface mount plastic packages with lens and daylight blocking filter. Filter bandwidth is matched with 870 nm to 950 nm IR emitters.
The TEMD1000‑1040 series are surface‑mount silicon PIN photodiodes offering high speed response and high radiant sensitivity. Each device includes a lens and a daylight‑blocking filter matched to 870‑950 nm IR emitters, making them suitable for infrared remote‑control and free‑air data‑transmission systems.
The document provides detailed specifications such as package dimensions, electrical ratings, optical characteristics, ordering information, and handling precautions. It also includes recommended reflow solder profiles and legal disclaimer information.
| Package type | surface mount |
|---|---|
| Package form | GW, RGW, yoke, axial |
| Dimensions (L×W×H) | 2.5 mm × 2 mm × 2.7 mm |
| Radiant sensitive area | 0.23 mm² |
| Reverse voltage (VR) | 60 V |
| Forward voltage (typical, IF=50 mA) | 11.3 V |
| Peak wavelength (λp) | 940 nm |
| Spectral bandwidth (λ0.5) | 790 nm – 1050 nm |
| Rise time (tr) | 4 ns |
| Fall time (tf) | 4 ns |
| Storage temperature range | -40 °C to +100 °C |
Store the devices at 5 °C to 35 °C with 60 % relative humidity.
The maximum reverse voltage is 60 V.
Typical forward voltage is 11.3 V at 50 mA.
The series is offered in GW, RGW, yoke, and axial package forms.
