Gigabyte GA-H61M-DS2 Motherboard User Manual

This is a user manual that introduces the hardware installation and BIOS program settings for the GA-H61M-DS2 motherboard.

Brand: Gigabyte
Category: Motherboard
Document type: User Manual
Language: Chinese
Pages: 40
File format: PDF
File size: 14.1 MB
Published: 11 May, 2012
Updated: 30 September, 2023
Model: GA-H61M-DS2
MD5 checksum: 51CDF1049D0F3B2EAA24A12D6B263DB7
PDF: Gigabyte GA-H61M-DS2 Motherboard User Manual PDF

About this manual

This manual explains how to install the GA-H61M-DS2 motherboard safely, covering pre‑installation precautions, connector and slot layout, BIOS configuration, and driver installation. It also includes a declaration of conformity and warranty information for Gigabyte products.

The document lists the technical specifications of the board, such as supported CPUs, memory types, expansion slots, storage interfaces, and USB ports, and provides guidance for troubleshooting and contacting Gigabyte support. This manual is written in Chinese.
