This is a PDF file that mainly introduces the characteristics and features of the MC 1,5/ 9-ST-3.5 connector.
The MC 1,5/9-ST-3,5 is a screw‑connection terminal block with a nominal current of 8 A and a rated voltage of 160 V. It features a 3.5 mm pitch, nine positions, and a compact height of 11.4 mm. Technical specifications such as dimensions, tightening torque and surge voltage ratings are listed in the handbook.
The document also provides part numbers for accessories like marker cards and screwdrivers, and references additional compatible products in the MC series. Contact information for Phoenix Contact and certification details (UL, CSA) are included at the end of the handbook.
| Nominal current | 8 A |
|---|---|
| Rated voltage | 160 V |
| Pitch | 3.5 mm |
| Number of positions | 9 |
| Height | 11.4 mm |
| Dimension a | 28 mm |
| Screw thread | M2 |
| Tightening torque | 0.22 Nm |
The nominal current is 8 A.
It has nine positions.
The pitch is 3.5 mm.
The height is 11.4 mm.
