UT 2,5-PE is a terminal block produced by TE Connectivity, with a maximum conductor cross section of 2.5 mm², a maximum AWG of 12, and a green-yellow color. It is suitable for conductors with a cross section of 0.14 - 2.5 mm².
The UT 2,5-PE is a universal terminal block featuring a screw connection, designed for conductor cross sections from 0.14 mm² to 2.5 mm² (flexible) and up to 4 mm² (rigid). It is supplied in a green‑yellow low color and complies with UL‑94 V0 flammability.
Key dimensions are a width of 5.2 mm, length of 46.9 mm, and heights of 47.5 mm (NS 35/7,5) or 55 mm (NS 35/15). The block supports a rated surge voltage of 8 kV, surge voltage category III, and requires a minimum tightening torque of 0.6 Nm.
| Conductor cross section flexible max | 2.5 mm² |
|---|---|
| Conductor cross section rigid max | 4 mm² |
| Number of connections | 2 |
| Rated surge voltage | 8 kV |
| Insulating material | PA |
| Color | green‑yellow low |
| Width | 5.2 mm |
| Length | 46.9 mm |
| Height NS 35/7,5 | 47.5 mm |
| Height NS 35/15 | 55 mm |
| Screw thread | M3 |
| Tightening torque (min) | 0.6 Nm |
| Stripping length | 9 mm |
It uses a screw connection.
The rated surge voltage is 8 kV.
A minimum tightening torque of 0.6 Nm is required.
The block is green‑yellow low in color.
