DR-DX5SU is a Panasonic HDD+DVD+MiniDV triple recorder with 250GB HDD, featuring 6-way dubbing, Bit-Rate Optimizer, High-Speed Dubbing (Max. 64x), and Super MPEG Encode Pre- & Post-Processors.
This manual covers the JVC DR-DX5SU triple‑recorder, which combines a 250 GB hard‑disk, DVD playback/recording, and MiniDV capture in a single unit. It explains how to set up the device, navigate the library database, and use its various recording and playback functions.
Key features include 6‑Way dubbing, Bit‑Rate Optimizer, high‑speed dubbing up to 64×, progressive‑scan output, Dolby Digital/DTS audio, and a high‑resolution multilingual GUI. The manual also lists power requirements, dimensions, and detailed specifications for audio and video formats.
| HDD Capacity | 250 GB |
|---|---|
| Maximum Recording Time (HDD) | Up to 473 hours |
| Power Consumption (On) | 49.0 W |
| Power Consumption (Standby) | 12.0 W |
| Audio D/A Converter | 192 kHz / 24‑bit |
| Output Level | 2.0 V RMS |
It can record MiniDV, HDD, DVD‑RAM, DVD‑RW (VR and Video formats), and DVD‑R.
The 250 GB hard drive provides up to 473 hours of recording time.
Yes, it includes a progressive‑scan output for both video and film sources.
