VLMK/Y82.. is one of the most robust and light efficient LEDs in the market. Its ceramic package makes it the ideal light source in applications of high thermal considerations allowing the additional current drive for a maximum light output while maintaining a high service life of up to 50K h.
The VLMK/Y82.. series is a high‑power SMD LED using AlInGaP technology. It is suited for automotive lighting, backlighting, signal and marker lights, and other applications where low thermal resistance and high optical efficiency are required.
The datasheet lists absolute maximum ratings, optical and electrical characteristics, package dimensions, storage and handling instructions, and compliance information such as RoHS and AEC‑Q101 automotive qualification.
| Forward current (IF) | 400 mA |
|---|---|
| Power dissipation (Ptot) | 1360 mW |
| Junction temperature (Tj) | +115 °C |
| Operating temperature range (Tamb) | -40 °C to +100 °C |
| Optical efficiency | 28 lm/W |
The recommended storage temperature is 10 °C to 30 °C.
The sealed bag has a shelf life of 12 months at less than 40 °C and less than 90 % relative humidity.
Yes, they are lead‑free and comply with RoHS 2002/95/EC.
