The TD62101 series consists of four high‑voltage Darlington driver ICs (TD62101, TD62103, TD62104, TD62105) offered in P (DIP‑16) and F (SOP‑16) packages. Each device provides seven NPN Darlington pairs for driving loads requiring up to 500 mA continuous output current.
Key specifications include a maximum output sustaining voltage of 25 V, input voltage range of –0.5 V to 30 V, and operation over –40 °C to 85 °C. The datasheet provides detailed pin‑out diagrams, maximum ratings, recommended operating conditions, and test circuit examples.
| Output current (single output) | 500 mA (max) |
|---|---|
| Output sustaining voltage | 0 ~ 25 V |
| Input voltage | -0.5 ~ 30 V |
| Power dissipation | 0.625 W |
| Package weight (DIP‑16) | 1.11 g (typ.) |
| Package weight (SOP‑16) | 0.16 g (typ.) |
Each channel can source up to 500 mA continuously.
The series is offered in a DIP‑16 (P) package and an SOP‑16 (F) package.
The output sustaining voltage can reach up to 25 V.
