This document is a product guide for Toshiba semiconductor products. The guide includes a list of products categorized by function and application, package diagrams, taping information, a list of lead-formed products, and an overall list of devices. Toshiba power transistors achieve high levels of current efficiency through the use of minute patterns and high-density MET design.
The Toshiba BCE0016A product guide lists power transistor families, their package types (TO‑3P(N), TO‑3P(L), TO‑220NIS, etc.) and performance ranges such as collector power output from 60 W to 220 W. It includes selection tables for high‑frequency, low‑frequency and audio‑amplifier applications, as well as maximum voltage and current ratings.
The guide also provides a complete package line‑up, tape‑packing information for automated assembly, and contact details for Toshiba’s worldwide subsidiaries. It is intended for designers selecting Toshiba semiconductor devices for a variety of electronic products.
| Collector power output | 60 W to 220 W |
|---|---|
| Collector‑emitter voltage (Vceo) | 10 V to 100 V |
| Maximum collector current (Ic) | 1 A to 5 A |
The transistors are rated for Vceo from 10 V up to 100 V.
Collector power output ranges from 60 W to 220 W depending on the package.
Yes, TO‑126 and TO‑220 packages are offered in TPS (1.3 mm) and TPL (1.8 mm) tape formats.
