The AD7538 is a 14-bit monolithic CMOS digital-to-analog converter (DAC) that uses laser trimmed thin-film resistors to achieve excellent linearity. The DAC is loaded by a single 14-bit wide word.
The AD7538 14‑bit DAC offers monotonic performance across the full temperature range, low‑cost upgrade for 12‑bit systems, and a small 24‑lead package. It features double‑buffered inputs, optional low‑leakage configuration, and operates from a +11.4 V to +15.75 V supply.
The document provides functional block diagrams, pin descriptions, electrical specifications, timing characteristics, absolute maximum ratings, application hints, and interfacing examples for 8086 and MC68000 microprocessors, as well as ordering information for various package options.
