This product is a CMOS dual 8-bit buffered multiplying DAC with features of +5 V to +15 V operating voltage range, DAC accuracy of 1%, four quadrant multiplication, TTL/CMOS compatible latch, applications in digital control of gain/attenuation filter parameters, stereo audio circuits and X-Y graphics.
The AD7528 dual 8‑bit buffered multiplying DAC provides two matched DAC channels with on‑chip latches, suitable for digital control of gain, attenuation, filter parameters, stereo audio and graphics. It operates from a +5 V to +15 V supply and consumes only about 20 mW.
The device is available in 20‑lead DIP, SOIC, PLCC and ceramic (Cerdip) packages, supports TTL/CMOS compatible inputs, and offers specifications such as 8‑bit resolution, ±50 nA to ±400 nA output leakage, and a wide temperature range of –40 °C to +125 °C for extended grades.
| Operating Voltage | +5 V to +15 V |
|---|---|
| Package Options | 20‑lead DIP, SOIC, PLCC, Cerdip |
| Temperature Range (Commercial Grades) | -40 °C to +85 °C |
The AD7528 operates from a +5 V to +15 V power supply.
It is offered in 20‑lead DIP, SOIC, PLCC and ceramic (Cerdip) packages.
