12CWQ10FNPbF is a 12A Schottky rectifier from IRF. This diode features low forward voltage drop and small footprint, making it suitable for applications such as disk drives, switching power supplies, converters, free-wheeling diodes, battery charging, and reverse battery protection.
The 12CWQ10FNPbF is a surface‑mount, center‑tap Schottky rectifier designed for low forward drop and a small footprint on PC boards. It is suited for applications such as disk drives, switching power supplies, converters, battery charging and reverse‑battery protection.
The leaflet lists key specifications including a 100 V reverse voltage rating, 6 A average forward current, 0.80 V typical forward voltage drop at 6 A, and a junction temperature range of –55 °C to 150 °C. Mechanical details, package dimensions (D‑Pak/TO‑252AA), weight, and tape‑and‑reel ordering options are also provided.
| Maximum Forward Voltage Drop @ 6 A | 0.80 V |
|---|---|
| Package Type | D‑Pak (TO‑252AA) |
| Approximate Weight | 0.3 g |
At 6 A and 25 °C the typical forward voltage drop is 0.80 V.
It is supplied in a D‑Pak (TO‑252AA) surface‑mount package.
Specify the part number, orientation, and quantity; reels are in multiples of 2,000 pieces for TR and 3,000 pieces for TRL/TRR.
