This manual describes the functions and features of the Delta PSC 3 controller, including the user interface, physical connections, and modules.
The Delta PSC 3 controller is a modular power system controller that can be used for small to large, complex power installations. It includes a central unit with basic I/O, a CAN‑based IMBUS communication bus, and optional external modules for monitoring and control. The integrated PLC and web server enable flexible monitoring, remote alarms, and configuration via Ethernet, modem, or LAN.
The manual covers the controller’s features, functional overview, user interfaces (web and local), physical connection options, and detailed descriptions of each module, such as the User Interface Module, String Sensor Module, and Fan Speed Controller. It also provides information on alarm levels, battery management functions, and AC measurement capabilities.
| Digital relay outputs | 6 |
|---|---|
| Digital open collector outputs | 4 |
| Digital inputs | 4 |
| Temperature sensor inputs | 2 |
| CAN (IMBUS) interfaces | 2 |
| Alarm levels | 3 (Critical, Urgent, Non‑urgent) |
The PSC 3 supports three alarm levels: Critical, Urgent, and Non‑urgent.
Remote supervision can be performed over intranet, Internet, or modem, and the controller includes Ethernet and RS‑485 interfaces.
Yes, the controller can measure basic mains voltages using the connected rectifiers without external equipment.
An integrated web server provides a graphical interface that can be accessed with any standard web browser.
