The ADG1221/ADG1222/ADG1223 are low-static-current, low-leakage iCMOS dual SPST switches with a ±15V/+12V supply range, 3V logic-compatible inputs, a switch resistance of 120Ω, a switch capacitance of 2pF, a switch leakage of 20pA, and a 10-lead MSOP package.
The ADG1221, ADG1222, and ADG1223 are iCMOS dual SPST switches offering low charge injection (<0.5 pC) and low off‑capacitance (2 pF). They operate from a ±15 V or +12 V supply and feature 3‑lead MSOP packaging.
The document provides detailed specifications, pin configurations, functional block diagrams, and ordering information for designers of test equipment, data‑acquisition, and signal‑routing applications.
| Off capacitance | 2 pF |
|---|---|
| On resistance | 120 Ω |
| Supply range | 33 V |
| Input high voltage (Vint) | 2.0 V min |
| Input low voltage (Vint) | 0.8 V max |
| Charge injection | 0.1 pC typ |
| Off isolation | 75 dB typ |
The off‑capacitance is 2 pF.
They operate with a supply range of up to 33 V.
Typical on‑resistance is 120 Ω.
Typical charge injection is 0.1 pC.
