The TL-WA5210G 2.4GHz High Power Wireless Outdoor CPE is dedicated to WISP CPE solution and long distance wireless network solutions. It integrates the functions of a Wireless Access Point, WISP Client, high gain antenna and weatherproof enclosure. It features 12dBi high gain antenna, high output power and high RX sensitivity can significantly extend the transmission range to deliver a more stable wireless connection. The TL-WA5210G features high output power and high RX sensitivity can significantly extend the transmission range to reduce dead spots and to deliver a more stable wireless connection. With integrated 12dBi dual-polarized antenna, the TL-WA5210G would help you easy to build up to 15km long range wireless link. If you have higher gain antenna, it also supports distance control from 0km to 52.6km, which breaks through distance limitations in normal 802.11g devices, enables ultra-long distance wireless transmission. The TL-WA5210G provides three operation modes for multiple users to access the Internet: AP client router, AP router and AP.
The TL‑WA5210G 2.4 GHz High Power Wireless Outdoor CPE is designed for long‑distance WISP deployments. It combines a wireless access point, WISP client, 12 dBi dual‑polarized antenna and weather‑proof enclosure, offering high output power, high RX sensitivity and optional passive PoE for flexible installation.
The manual covers three operation modes (AP client router, AP router, AP), security options (WEP, WPA/WPA2, WPA‑PSK/WPA2‑PSK with AES/TKIP), and detailed hardware specifications such as frequency range, transmit power limits, antenna beamwidth, power supply and environmental ratings.
| Frequency Range | 2.4-2.4835 GHz |
|---|---|
| Wireless Transmit Power (EIRP, CE) | <20 dBm |
| Peak Output Power (FCC) | <27 dBm |
| Wireless Signal Rates | 11g: 54/48/36/24/18/12/9/6 Mbps; 11b: 11/5.5/2/1 Mbps |
| Receiver Sensitivity (802.11g 54 Mbps) | -76 dBm |
| Wireless Range (Integrated Antenna) | 15 km |
| Maximum Wireless Range (High‑gain Antenna) | 50 km |
| Antenna Beamwidth Horizontal | 60° |
| Antenna Beamwidth Vertical | 30° |
| Operating Temperature | -30 °C ~ 70 °C |
| Storage Humidity | 5 % ~ 95 % Non‑Condensing |
| Dimensions | 10.4 × 4.7 × 3.2 in (265 × 120 × 83 mm) |
It supports AP client router mode (WISP CPE), AP router mode (Internet via ADSL/Cable modem), and AP mode, which includes Access Point, Client, WDS Bridge and Repeater functions.
With the built‑in 12 dBi dual‑polarized antenna it can reach up to 15 km, and up to 50 km when a high‑gain directional antenna is used.
Yes, the device supports passive Power over Ethernet for flexible deployment.
It offers 64/128/152‑bit WEP encryption, WPA/WPA2, and WPA‑PSK/WPA2‑PSK with AES/TKIP encryption.
