The MAX13101E/MAX13102E/MAX13103E/MAX13108E 16-bit bidirectional CMOS logic-level translators provide the level shifting necessary to allow data transfer in multivoltage systems.
The MAX13101E, MAX13102E, MAX13103E, and MAX13108E are 16‑channel buffered CMOS logic‑level translators that provide bidirectional voltage shifting without a direction pin. They support a wide supply range and are suited for multivoltage systems such as PDAs, digital cameras, and portable equipment.
Key features include an enable input for low quiescent current, a multiplexing input on the MAX13108E, +15 kV ESD protection on I/O VCC lines, and availability in 36‑bump WLP and 40‑pin TQFN packages. Electrical specifications cover supply ranges, data rates up to 20 Mbps, and detailed timing characteristics.
| VCC Supply Range | 1.65 V to 5.5 V |
|---|---|
| VL Supply Range | 1.2 V to VCC |
| Maximum Data Rate | 20 Mbps |
| Typical Quiescent Current | 0.03 pA |
| Package Options | 36‑bump WLP, 40‑pin TQFN |
The devices support up to 20 Mbps data rate.
VCC can be from 1.65 V to 5.5 V, and VL from 1.2 V up to VCC.
They are offered in 36‑bump WLP and 40‑pin TQFN packages.
