The CD54HC86 and CD74HC86 contain four independent EXCLUSIVE OR gates with low power consumption and broad applications.
The CD74HC86 and CD74HCT86 are quad 2‑input exclusive‑OR (XOR) gates built with high‑speed CMOS technology. They operate over a wide temperature range (‑55 °C to 125 °C) and are compatible with LSTTL loads, offering low power consumption compared to traditional LSTTL logic.
The document provides detailed electrical characteristics, absolute maximum ratings, switching specifications, pin configurations for various package types (PDIP, SOIC, CERDIP) and ordering information, including lead‑free and green RoHS‑compliant options.
| Typical Propagation Delay | 9 ns (VCC=5 V, CL=15 pF, TA=25 °C) |
|---|---|
| Supply Voltage Range (HC Types) | 2 V to 6 V |
| Operating Temperature Range | -55 °C to 125 °C |
The typical propagation delay is 9 ns measured at VCC = 5 V, CL = 15 pF and a temperature of 25 °C.
Both devices operate from –55 °C up to 125 °C.
The HC family can be powered from 2 V to 6 V.
