The SN74LV32A-Q1 is a quad 2-input positive-OR gate from TI. It operates from 2V to 5.5V, has a max tpd of 6.5 ns, and supports mixed-mode voltage operation and partial power-down operation.
The SN74LV32A-Q1 is a quadruple 2‑input positive‑OR gate designed for 2 V to 5.5 V supply operation. It implements the Boolean function Y = A + B and supports mixed‑mode voltage operation on all ports, as well as partial‑power‑down mode.
The document provides absolute maximum ratings, recommended operating conditions, electrical and noise characteristics, mechanical dimensions, land‑pattern data, and packaging options. It also includes important notices regarding warranty, availability and compliance for automotive, defense and medical applications.
| Supply voltage range | 2 V to 5.5 V |
|---|---|
| Maximum propagation delay | 6.5 ns at 5 V |
| Package type | TSSOP PW (tape and reel) |
The device operates with a supply voltage between 2 V and 5.5 V.
The maximum propagation delay is 6.5 ns when powered at 5 V.
It is offered in a TSSOP PW package, available in tape‑and‑reel form.
Yes, the device is qualified for automotive applications in the PW package.
