The 74AC11008 is a quad 2-input positive-AND gate from Texas Instruments. It performs the Boolean function Y=A•B or Y=A&B in positive logic. The 74AC11008 is characterized for operation from -40°C to 85°C.
The 74AC11008 is a CMOS logic device that contains four independent 2‑input positive‑AND gates. It operates over a temperature range of –40 °C to 85 °C and is characterized for typical latch‑up immunity of 500 mA at 125 °C. The device follows ANSI/IEEE Std 91‑1984 and IEC Publication 617‑12 for its logic symbol.
The part is offered in multiple packages, including Plastic Small‑Outline (D), Thin Shrink Small‑Outline (PW), and standard Plastic 300‑mil DIP (N). Key electrical ratings include a supply voltage range of 3 V to 5.5 V, continuous output current up to 50 mA, and a maximum power dissipation of 1.3 W for the D package. Detailed absolute‑maximum and recommended operating conditions are provided in the datasheet.
| Number of gates | 4 independent 2‑input AND gates |
|---|---|
| Operating temperature range | –40 °C to 85 °C |
| Latch‑up immunity | 500 mA at 125 °C |
It contains four independent 2‑input AND gates.
Package options include Plastic Small‑Outline (D), Thin Shrink Small‑Outline (PW), and standard Plastic 300‑mil DIP (N).
