The handbook lists the model numbers, physical dimensions, mounting options, and electrical characteristics of ALPS rotary potentiometers. It includes ordering tables, packaging notes, and details on shaft styles, switch types, and push‑lock mechanisms.
The devices are intended for car‑audio volume, tone, and balance control, as well as other audio and industrial applications. Various shaft diameters, travel distances, and resistance values are provided to help engineers select the appropriate part. This manual is written in Japanese.
| Travel (stroke) | 0.5 mm |
|---|
The push‑lock shaft travel is 0.5 mm.
