This document describes the specifications and characteristics of a potentiometer called RKlMHOAttCB. The potentiometer has a total resistance of 10 kn, a rated power of 0.05 W, a rated voltage of 50 V A.C. / 20 V D.C., a resistance taper of 6, and is made of polycarbonate material.
This document provides the full specifications for the ALPS 290214 potentiometer. It includes electrical characteristics such as resistance, rated power, voltage limits, insulation resistance, and withstanding voltage, as well as mechanical properties like total rotational angle, torque, shaft play, and endurance.
Additional sections describe marking requirements, packaging notes, and mounting tolerances. The specifications are intended for designers and manufacturers who need detailed performance data for this component. This manual is written in Chinese.
| Total resistance | 2 Ω |
|---|---|
| Maximum working voltage | 50 V AC, 20 V DC |
| Insulation resistance | >100 MΩ at 500 V DC |
| Withstand voltage | 500 V AC for 1 minute |
| Total rotational angle | 300° ± 5° |
| Rotational life | ≥15,000 cycles |
| Shaft play | ≤0.7 XL/30 mm |
It can operate up to 50 V AC or 20 V DC.
The potentiometer is rated for at least 15,000 cycles.
