The document introduces a series of TACT switches, including different models and features. These switches have different operating forces and travel distances, suitable for various applications. They have high performance and long life span, suitable for surface mount and snap-in type installations.
The Philips SKHHCWA010 is a TACT snap‑in surface‑mount switch from the SKHH series. It offers a soft‑feeling tactile action with selectable operating forces and multiple stem colors, suitable for audio, office, communication, measurement, TV, VCR and automotive applications.
The document provides detailed specifications, mounting dimensions, soldering conditions, and optional features such as anti‑ESD ground terminals and standard knobs. It also lists the full range of SKHH part numbers and their mechanical and electrical characteristics.
| Operating force | 0.98 N – 2.55 N |
|---|---|
| Maximum rating | 12 V DC |
| Operating life | 500,000 cycles |
The switch is rated for 500,000 operating cycles.
Available stem colors include black, dark gray, red, orange, and yellow.
Yes, the snap‑in type allows the switch to be mounted directly onto the PCB.
The switch can handle up to 12 V DC.
