EC12 series Insulated shaft type encoder is an encoder with a wide range of applications. A 12mm sized unit achieved high resolution,12 pulse/12 detent and 24 pulse/24 detent. Used a new structure for the shaft and bushing, and achieved a high precision, responsive system.
This datasheet describes the ALPS EC12 Series rotary encoders, covering both incremental and absolute types. It lists the available shaft options, detent configurations, and mechanical dimensions for each model.
Key electrical characteristics such as operating voltage, current, and signal output are detailed, along with mechanical performance data like operating life, torque, and environmental limits. The document also includes mounting dimensions and switch specifications for variants with push‑on switches.
| Operating life | 15,000 cycles (30,000 cycles for some models) |
|---|---|
| Resolution | 12 pulse/12 detent and 24 pulse/24 detent |
| Operating temperature range | –40 °C to 70 °C |
| Detent torque | Specified but value not given |
Typical operating life is 15,000 cycles, with some versions rated for 30,000 cycles.
The series offers 12 pulse/12 detent and 24 pulse/24 detent options.
They are rated for –40 °C to 70 °C.
