This document introduces the characteristics of RKJXM series 8-way stick switch products, including key operation force, operating angle, travel, contact resistance and other parameters. The product has single-axis and dual-axis structure, which can meet the needs of different application scenarios.
The RKJXM Series from Multi Control Devices combines an 8‑direction stick switch with a rotary encoder in a compact 20 mm package. It offers center‑push functionality, multiple operating angles, and tactile feedback for applications such as car audio, navigation systems and remote controllers.
The datasheet lists electrical performance, mechanical characteristics, dimensions, and test circuits. Key parameters include operating life up to 100 000 cycles, operating voltage of 5 V with 5 kΩ load, and various force and angle specifications for each direction. This manual is written in Chinese.
