This document provides the full technical specification for the ALPS SHOGSC48A slide switch, covering electrical ratings, mechanical dimensions, and environmental test conditions. It is intended for designers and engineers who need precise data for product integration and compliance testing.
Key parameters include contact resistance, insulation resistance, voltage proof test levels, operating force, and maximum current/voltage ratings, together with detailed test procedures for durability, shock, and humidity exposure.
| Contact resistance | 1 kΩ + 200 Ω (20 nΩ, 50 mA MAX) |
|---|---|
| Insulation resistance | 500 VDC measured after 1 min |
| Voltage proof test voltage | 500 VAC (50~60 Hz, cut‑off current 2 A) |
| Maximum rating (resistive load) | 12 VDC, 0.1 A |
| Operating force (static load) | 3 N |
The contact resistance must not exceed 1 kΩ + 200 Ω (20 nΩ, 50 mA MAX).
The switch has an insulation resistance of 500 VDC measured after 1 minute.
A voltage‑proof test of 500 VAC (50~60 Hz, cut‑off current 2 A) is applied.
A static load of 3 N is applied to the actuator root in the operating direction.
