This document is about the product specifications of ALPS ELECTRIC CO., LTD. The product is suitable for low current circuits (secondary circuits) with an operating temperature range of -40 to 85°C and a storage temperature range of -40 to 85°C. The appearance, construction, and dimensions meet the requirements. The switch has good finishing with no rust, cracks, or plating failures. The electrical specifications are 12V DC 0.1A (no load) and 12V DC 0.5A (with load).
The ALPS STSSS9132 is a low‑current slide switch intended for electronic equipment such as audio‑visual and communication devices. The document provides the mechanical dimensions, appearance requirements, and detailed test conditions for robustness, wobble, shock, and solderability.
Electrical characteristics include contact resistance, insulation test voltage, voltage proof test, and operating force specifications. Environmental limits such as operating temperature, storage temperature, humidity, and pressure are also defined, along with recommended soldering flux and long‑term storage guidelines.
| Operating temperature range | -40 °C to +85 °C |
|---|---|
| Storage temperature range | 40 °C to 85 °C |
| Insulation test voltage | 600 V DC |
| Voltage proof test voltage | 509 V AC (50‑60 Hz) |
| PCB thickness | 1.6 mm |
| Operating life without load | 10,000 cycles at 15‑20 cpm |
The switch can operate from –40 °C up to +85 °C.
It is rated for 10,000 cycles at 15‑20 cycles per minute without load.
The insulation test voltage is 600 V DC.
