This document introduces the features and characteristics of the Sony DSR-570WS and DSR-370 high-quality DVCAM camcorders. The DSR-370 is a high-performance DVCAM camcorder with three high-performance 1/2-inch Power HAD CCDs, providing a resolution of 800 TV lines, same as the DSR-570WS. The DSR-570WS is a top-of-the-line DVCAM camcorder that supports both widescreen 16:9 and standard 4:3 aspect ratios. It is equipped with three 2/3-inch Power HAD WS CCDs, achieving a resolution of 850 TV lines in 4:3 mode and 800 TV lines in 16:9 mode. These camcorders deliver superb picture quality and are suitable for various creative shooting environments.
The DSR-570WS/570WSP and DSR-370/370P are compact, lightweight 3CCD digital camcorders designed for both field and studio use. They support NTSC/PAL DVCAM recording, 26‑pin CCU control, and optional accessories such as video disk units and wireless receivers.
This manual covers the camcorders' features, camera setup files, remote‑control options, detailed specifications, and recommended accessories. It also explains how to connect to studio equipment, use the ClipLink system, and operate advanced functions like Hyper Gain, TruEye, and DynaLatitude.
| Horizontal resolution (4:3 mode) | 850 TV lines |
|---|---|
| CCD sensor (DSR-570WS) | Three 2/3‑inch type Power HAD WS CCDs |
| CCD sensor (DSR-370) | Three 1/2‑inch type Power HAD CCDs |
| Weight (camcorder body only) | 7 lb 15 oz (3.6 kg) for DSR-570WS, 7 lb 4 oz (3.3 kg) for DSR-370 |
| Maximum recording time (standard PDV‑184ME cassette) | 184 minutes |
The DSR-570WS is equipped with three 2/3‑inch type Power HAD WS CCDs, each with about 520,000 pixels.
The camcorder delivers 850 TV lines of horizontal resolution in 4:3 mode.
