The SSC-DC693P is a surveillance camera from Panasonic. It features a 1/3-inch image sensor with Dynaview+ technology, which offers extremely wide dynamic range for capturing clear images even in strong backlight environments. This camera produces extremely clear and detailed images and is an excellent choice for monitoring applications that demand high performance.
The SSC-DC693P incorporates a 1/3-type image sensor with Dynaview+ technology, delivering a very wide dynamic range and clear images even in strong backlight. It offers a Day/Night function that automatically switches to black‑and‑white mode with a clear filter for low‑light operation as low as 0.05 Ix.
Technical specifications include a 720 × 540 pixel resolution, 520 TV‑line horizontal resolution, PAL sync, 4× digital zoom, up to 48 dB AGC gain, and power consumption under 8 W. The camera operates from –10 °C to 50 °C, stores from –40 °C to 60 °C, and measures 56 × 68.8 × 131 mm (≈420 g) without the tripod.
| Image sensor type | 1/3-type image sensor with Dynaview+ technology |
|---|---|
| Minimum illumination (Color) | 0.8 Ix |
| Minimum illumination (B/W) | 0.01 Ix |
| AGC gain range | 0‑48 dB (manual) |
| Power consumption | Less than 8.0 W |
| Power requirements | AC 220‑230 V 10% |
| Dimensions (W × H × D) | 56 × 68.8 × 131 mm (without Tripod) |
| Mass | Approx. 420 g |
| Operating temperature | -10 °C to 50 °C |
| Storage temperature | -40 °C to 60 °C |
| Horizontal resolution | 520 TV lines |
| Picture elements (H × V) | 720 × 540 |
| Sync system | PAL standard |
| Signal system | INT/AC Line Lock |
The camera can operate at a minimum illumination of 0.01 Ix in black‑and‑white mode.
Yes, it automatically switches to black‑and‑white mode with a clear filter when illumination drops, allowing operation down to 0.05 Ix.
