The ANSMANN 8194047 is a plug‑in AC/DC power supply designed for medical equipment. It accepts a universal input voltage of 100‑240 V AC at 50/60 Hz and provides a regulated 12 V DC output with a maximum current of 600 mA. Stand‑by power consumption is below 0.3 W and the unit can deliver up to approximately 10 W under load.
The device complies with medical safety standards (EN 60601‑1, IEC 61558) and carries CE and Bureau Veritas marks. It is rated IP 20, operates between –40 °C and 40 °C, and can be stored from –25 °C to 70 °C. Packaging is a white folding box (≈68 × 41 × 73 mm) with individual units. This manual is written in German.
| Input voltage | 100‑240 V AC, 50/60 Hz |
|---|---|
| Output voltage | 12 V DC (regulated) |
| Output current | 600 mA |
| Stand‑by power consumption | < 0.3 W |
| Maximum power | ≈10 W |
| Ripple voltage | < 300 mV |
| Protection class | Class I |
| Operating temperature | -40 °C … 40 °C |
| Storage temperature | -25 °C … 70 °C |
It accepts 100‑240 V AC at 50/60 Hz.
The output is a regulated 12 V DC.
It can supply up to 600 mA of output current.
Stand‑by power consumption is less than 0.3 W.
