The MC10H211 is a dual 3 input 3 output NOR gate, which can drive up to 6 transmission lines simultaneously. It can also wire OR several levels of gating for minimization of gate and package count. The ability to control three parallel lines with minimum propagation delay from a single point makes the MC10H211 particularly useful in clock distribution applications where minimum clock skew is desired.
The MC10H211 is a dual 3‑input 3‑output NOR gate designed for clock distribution and low‑skew applications. It offers features such as 1.0 ns typical propagation delay, 160 mW typical power dissipation, and voltage‑compensated operation, with compatibility to MECL‑10K devices.
The document includes detailed electrical characteristics, maximum ratings, AC characteristics, pin assignments for various packages (CDIP‑16, PDIP‑16, PLCC‑20), ordering information, and package dimension drawings. Application notes and literature references are also listed for further design guidance.
| Propagation Delay (typical) | 1.0 ns |
|---|---|
| Power Dissipation (typical) | 160 mW |
| Continuous Output Current (max) | 50 mA |
| Operating Temperature Range | -55 °C to +75 °C |
| Package Options | CDIP‑16, PDIP‑16, PLCC‑20, SOEIAJ‑16 |
The typical propagation delay is 1.0 ns.
The device can source up to 50 mA continuously.
The MC10H211 is offered in CDIP‑16, PDIP‑16, PLCC‑20, and SOEIAJ‑16 packages.
The device operates from –55 °C up to +75 °C.
