MC10103 is a quad 2-input OR gate with OR/NOR outputs. It features low power consumption and short propagation delay.
The MC10103 is a quad 2‑input OR gate offering both OR and NOR outputs. It is supplied in CDIP‑16, PDIP‑16, and PLCC‑20 packages for flexible board‑level integration.
Key electrical parameters include a typical propagation delay of 1.0 ns, rise and fall times of about 3.6 ns, and a typical input current of 0.3 µA. Detailed pin assignments, marking codes, and mechanical dimensions are provided for each package type.
| Propagation Delay (typical) | 1.0 ns |
|---|---|
| Rise Time (20‑80%) | 3.6 ns |
| Fall Time (20‑80%) | 3.6 ns |
| Input Current (typical) | 0.3 µA |
The typical propagation delay is 1.0 ns.
