This manual covers the features of the Sanyo PLC‑XU350 ultra‑portable multimedia projector, including its simple wireless setup using a provided USB memory stick, auto‑setup functions, and built‑in 7 W speaker for conference‑room use. It also lists the accessories supplied with the unit and safety cautions for proper operation.
Detailed technical specifications are provided, such as brightness, lamp wattage, contrast, resolution, zoom range, dimensions, weight, power consumption, and available audio/video and control interfaces. Replacement lamp information and compliance certifications are also included.
| Brightness (typical) | 3500 lm |
|---|---|
| Lamp wattage | 225 W |
| Contrast | 500:1 |
| Resolution (pixels) | 1024 x 768 (2,359,296 pixels) |
| Zoom / Focus | 1‑1.6 (manual driven) |
| Dimensions (W×H×D) | 326.0 × 83.1 × 231.6 mm |
| Weight | 2.9 kg |
| Power consumption (Normal) | 310 W |
Plug the provided USB memory stick into a PC, select "Network capture", and click OK to automatically set up the wireless LAN.
The PLC‑XU350 provides a typical brightness of 3500 lumens.
The projector uses replacement lamp type POA‑LMP131.
It includes RCA video, Mini‑DIN 4‑pin S‑Video, and a D‑sub 15‑pin component input.
