TI TFP410 is a Texas Instruments PanelBus flat panel display product, part of a comprehensive family of end-to-end DVI 1.0-compliant solutions, targeted at the PC and consumer electronics industry.
The TFP410 is a Texas Instruments PanelBus flat‑panel display transmitter that offers a universal interface for DVI‑compliant graphics controllers. It supports selectable bus widths, adjustable signal levels, and both differential and single‑ended clocking, enabling resolutions up to UXGA at 165 MHz.
The document includes a functional block diagram, detailed pin assignments, terminal function descriptions, configuration and programming information, absolute maximum ratings, recommended operating conditions, electrical characteristics, timing diagrams, and layout guidelines for the 64‑pin TQFP package.
| Typical Vpp (operating supply voltage) | 3.3 V (3.0 V – 3.6 V) |
|---|---|
| IDCK clock frequency | 25 MHz – 165 MHz |
| Package | 64‑pin TQFP |
Typical Vpp is 3.3 V, with a recommended range of 3.0 V to 3.6 V.
The TFP410 is supplied in a 64‑pin TQFP package.
DKEN enables the data de‑skew function, allowing adjustment of the setup and hold times for the pixel data inputs.
