ISL84516 and ISL84517 are Intersil-designed low-voltage, dual-supply, SPST, analog switches that operate from ±1.5V to ±6V.
The ISL84516 (normally open) and ISL84517 (normally closed) are low‑voltage, dual‑supply SPST analog switches designed for battery‑powered equipment. They operate from +1.5 V to +6 V, feature a low on‑resistance of 13 Ω, fast switching (40 ns turn‑on, 30 ns turn‑off) and low leakage currents.
The datasheet provides detailed electrical specifications, absolute maximum ratings, pinout diagrams for SOIC and SOT‑23 packages, test circuit examples, and guidance on power‑supply sequencing and over‑voltage protection. It also includes typical performance curves, package dimensions and RoHS compliance information.
| Supply Voltage Range | +1.5 V to +6 V |
|---|---|
| On‑Resistance (Ron) at +5 V | 13 Ω |
| ESD Rating | >2 kV (MIL‑STD‑883 Method 3015) |
| Package Types | 8‑lead SOIC, 5‑lead SOT‑23 |
| RoHS Compliance | Pb‑free, RoHS compliant |
They operate from +1.5 V up to +6 V.
The on‑resistance is 13 Ω.
Yes, they are Pb‑free and RoHS compliant.
