The AT22V10/AT22V10L is a CMOS high-performance EPROM-based programmable logic device (PLDs), with speeds down to 15 nanoseconds and power dissipation as low as 12 mA. All speed ranges are specified over the full 5 V ±10% range. All pins offer a low ±10 µA leakage. The AT22V10L provides the optimum low power CMOS PLD solution, with low DC power (8 mA typical) and full CMOS output levels. The AT22V10L significantly reduces total system power and enhances system reliability. Full CMOS output levels help reduce power in many other system components.
The AT22V10/L is a CMOS high‑performance EPROM‑based programmable logic device (PLD) offering propagation delays as low as 15 ns and low power dissipation. It supports both commercial and military temperature ranges, provides full CMOS output levels, and includes optional synchronous preset and asynchronous reset product terms.
The document provides detailed absolute maximum ratings, DC and AC characteristics, functional logic diagrams, preload and erase procedures, as well as ordering information and package options for the device.
| Maximum Propagation Delay | 15 ns |
|---|---|
| Supply Voltage Range | 5 V ±10% |
| Operating Temperature (Commercial) | 0°C to 70°C |
| Input Leakage Current | 12 mA (typical) |
| ESD Protection | 2000 V |
The device has a maximum propagation delay of 15 ns.
It operates from a 5 V supply with a ±10 % tolerance.
The commercial version is rated from 0 °C to 70 °C.
The entire fuse array is erased by exposing the device to UV light at 253.7 nm for at least 20 minutes.
