AT91SAM9263-EK Evaluation Board User Guide
This guide describes the AT91SAM9263-EK evaluation kit, which enables evaluation and code development for applications running on an AT91SAM9263 microcontroller. It lists the kit contents, safety warnings, and provides a block diagram of the board.
The document covers board setup, power requirements, connector descriptions, jumper settings, schematics, and revision history, helping users to get the hardware up‑and‑running and understand its features.
| SDRAM | 64 Mbytes |
|---|---|
| PSRAM | 4 Mbytes on EBI1 |
| NAND Flash | 256 Mbytes |
| NOR Flash | Footprint only |
| Hard disk connector | 1.8" |
| USB device port | 1 interface |
| USB host ports | 2 interfaces |
| RS232 port | 1 serial port |
| DBGU port | 1 serial port |
| CAN port | CAN 2.0B |
| Ethernet | 100‑base TX with three LEDs |
| Audio DAC | AC97 |
| LCD module | 3.5" 1/4 VGA TFT with TouchScreen |
| Camera interface | ISI connector |
| User input buttons | 2 push buttons |
| Wakeup button | 1 push button |
| Reset button | 1 push button |
| Card slot | DataFlash/SD/SDIO/MMC |
An AC/DC power adapter providing 12 V at 1 A with a 2.1 mm × 5.5 mm plug is required.
