The Am29F016D is a 16 megabit (2M x 8-bit) CMOS 5.0 Volt-only, Uniform Sector Flash Memory.
The Am29F016D is a 16‑Mbit, 5.0 V‑only CMOS flash memory offered by AMD and Fujitsu. It is available in 48‑pin TSOP, 40‑pin TSOP, 44‑pin SO, and Known Good Die (KGD) packages. The device supports single‑supply operation, embedded erase and program algorithms, and a variety of protection features.
Key features include up to 1,000,000 program/erase cycles per sector, 20‑year data retention at 125 °C, 32 uniform 64‑KB sectors, and access times as fast as 70 ns. The datasheet details pin assignments, command sequences, timing diagrams, and electrical characteristics for designers integrating the part into their systems.
| Memory capacity | 16 Mbit (2 M × 8 bit) |
|---|---|
| Operating voltage | 5.0 V single supply |
| Access time (fastest) | 70 ns |
| Active read current | 25 mA typical |
| Program/erase current | 30 mA typical |
| Standby current | 1 A typical |
| Sector architecture | 32 uniform sectors of 64 KB each |
| Package options | 48‑pin TSOP, 40‑pin TSOP, 44‑pin SO, KGD |
| Program/erase endurance | ≥ 1,000,000 cycles per sector |
| Data retention | 20 years at 125 °C |
| Process technology | 0.23 µm |
The device operates from a single 5.0 V power supply.
Each sector is guaranteed to endure at least 1,000,000 program/erase cycles.
It is offered in 48‑pin TSOP, 40‑pin TSOP, 44‑pin SO, and Known Good Die (KGD) packages.
The device contains 32 uniform sectors, each 64 KB in size.
