This user manual introduces the basic operation of DVR, the use method, the main function introduction, precautions, etc.
This manual covers the hardware installation, including hard‑drive and DVD‑writer setup, front and rear panel connections, and sensor/alarm installation. It also explains basic functions such as power on/off, login, recording modes, playback, and PTZ control, as well as menu navigation and configuration.
Additional sections describe remote and mobile surveillance, system management tasks like formatting disks and updating firmware, and detailed specifications for both 8‑channel and 16‑channel models, including video/audio formats, network interfaces, and power requirements.
| Compression format | Standard H.264 Baseline |
|---|---|
| Video output | Composite 1.0V p‑p/75Ω, BNC×2, S‑VIDEO×1, VGA×1 |
| Video input (16‑channel) | Composite 1.0V p‑p/75Ω, BNC×16 |
| Display resolution | 720×576 (PAL), 720×480 (NTSC) |
| Record resolution | 352×288, 704×576 (PAL), 352×240, 704×480 (NTSC) |
| Audio input | -8 dB ~ 22 kHz, RCA ×4 |
| Alarm input (16‑channel) | 16 CH (NO or NC) |
| Network interface | RJ45 (LAN, INTERNET) |
| Power supply (16‑channel) | 12 V 5 A |
The 16‑channel model uses a 12 V 5 A power supply, while the 8‑channel model uses a 12 V 4 A supply.
The 16‑channel DVR provides 16 alarm inputs (NO or NC).
It uses the Standard H.264 Baseline compression format.
