DVMD1-X is a digital video motion detector provided by Radiant Inc., which can detect motion and generate alerts. It has a working temperature range of 0-60C and can be powered by 8 to 36VDC or 24VAC.
The Digital Video Motion Detector DVMD1‑X is a compact, aluminum‑cased device that processes video input and provides overlay video output with a dry‑contact alarm. It includes a DSP, power input, video BNC connectors, a network RJ45 port, and a PTZ RJ12 connector.
The manual covers technical specifications, power requirements, wiring diagrams, alarm relay wiring, network setup, PTZ jumper settings, and step‑by‑step connection instructions. It also explains how to use the ManagerNET.exe software and where to obtain firmware updates.
| Operating temperature range | 0-60°C |
|---|---|
| Power input voltage | 8‑36 VDC or 24 VAC |
| Minimum 12 V supply rating | ≥1.1 W (12 V @ 100 mA) |
| Part number | 801-004 |
| Physical dimensions | 3.5" × 5" × 1.25" |
It accepts 8 to 36 VDC or 24 VAC as its power source.
The alarm relay uses three terminals: NC (normally closed when power is off), COM (common), and NO (normally open when power is off and opens on alarm).
The unit address is internally set to FFO.
