This is a technical literature for TFT-LCD module LQ104V1LG61
The Sharp LD-17Y59A is a 10.4" color active‑matrix TFT‑LCD module that uses an amorphous‑silicon TFT array. It provides a 640×480 pixel display with 262,144 colors and a low‑reflection, high‑saturation panel suitable for multimedia applications. The module integrates driver ICs, control circuitry, a power‑supply circuit and a backlight unit, and interfaces via LVDS signals.
The document lists the module's mechanical and electrical specifications, pin assignments, maximum ratings, and recommended operating conditions. It also includes revision records, lot labeling information, and connector details for integration into electronic equipment.
| Display size | 26 (10.4") Diagonal cm |
|---|---|
| Active area | 211.2(H)×158.4(V) mm |
| Pixel format | 640(H)×480(V) pixel |
| Number of colors | 262,144 colors |
| Pixel pitch | 0.330(H)×0.330(V) mm |
| Mass | 620 (max) g |
| Operating temperature | -30 °C to +80 °C |
| Maximum humidity | 95 %RH (≤40 °C) |
It has a 640×480 pixel format with 262,144 colors.
It can operate from –30 °C up to +80 °C.
The LVDS signals use connector FI‑SE20M (JAE) or FI‑S208 (JAE).
