This installation guide describes how to install and use the ASRock 939SLI32-eSATA2 motherboard.
This Quick Installation Guide introduces the ASRock 939SLI32-eSATA2 motherboard, lists the package contents, and provides an overview of its key specifications such as CPU socket, chipset, memory support, and expansion slots. It also points users to the full User Manual on the support CD for detailed configuration.
The guide includes safety precautions, detailed installation steps for the CPU, memory, and peripherals, BIOS configuration notes, and information on RAID, eSATAII, and over‑clocking features. A Spanish appendix at the end covers SATA mode selection and BIOS access.
| Form Factor | ATX (12.0‑in x 9.6‑in) |
|---|---|
| CPU Socket | 939‑Pin socket supporting AMD Athlon™ 64 / 64FX / 64X2 |
| Chipset | Northbridge ULi® M1695, Southbridge ULi® M1697 |
| Memory Slots | 4 DDR DIMM slots, DDR400/333/266, max 4 GB |
| Audio Codec | Realtek ALC660 5.1‑channel |
It uses a 939‑Pin socket that supports AMD Athlon 64, 64FX and 64X2 processors.
Yes, the SATAII connectors support RAID 0, 1, 0+1, JBOD and 5.
