ASRock AD525PV / AD425PV Motherboard User Manual

AD525PV/AD425PV User Manual

Brand: ASRock
Category: Motherboard
Document type: User Manual
Language: English
Pages: 46
File format: PDF
File size: 353 KB
Published: 02 May, 2012
Updated: 30 September, 2023
Models: AD525PV, AD425PV
MD5 checksum: E62D34DAABC76619AB5F5117D49EAE34
PDF: ASRock AD525PV / AD425PV Motherboard User Manual PDF

About this manual

This manual covers the AD525PV and AD425PV Mini‑ITX motherboards, detailing hardware installation, BIOS configuration, and software support. It includes safety notices, warranty disclaimer, and regulatory compliance information.

The guide walks you through step‑by‑step installation of memory, CPU, SATA drives, and expansion cards, then explains BIOS menus for overclocking, power management, and security settings. A support CD with drivers and utilities is also described.

What's inside

Introduction
Installation
BIOS Setup Utility
Motherboard Layout
Security Screen
Boot Screen
Software Support
Specifications

Specifications

Form Factor	Mini‑ITX (6.7" x 6.7")
CPU	Intel Dual‑Core Atom D525 / Atom D425
Chipset	Intel NM10 Express
Memory Slots	2 x DDR2 DIMM (max 8 GB)
Graphics	Intel GMA 3150, max shared 384 MB
Audio	5.1 CH HD Audio (VIA VT1705)
LAN	Gigabit Ethernet (Realtek RTL8111DL)
SATA Ports	2 x SATAII 3.0 Gb/s (NCQ, AHCI, Hot‑Plug)

Frequently asked questions

What CPUs are supported by the AD525PV / AD425PV motherboard?

It supports Intel Dual‑Core Atom D525 for the AD525PV model and Intel Atom D425 for the AD425PV model.

How many SATA ports does the board provide?

The motherboard includes two SATAII 3.0 Gb/s connectors with NCQ, AHCI and Hot‑Plug support.

What is the form factor of this motherboard?

It is a Mini‑ITX board measuring 6.7 inches by 6.7 inches.
