The ASRock 2Core1333-2.66G motherboard is a high-performance and stable product. It features a wide range of functions and characteristics, making it suitable for various computing needs.
This Quick Installation Guide introduces the ASRock 2Core1333-2.66G Micro‑ATX motherboard and walks users through unpacking, component identification, and installation procedures. It also points to the full user manual on the support CD for more detailed information.
Key hardware details are listed, including the LGA 775 socket, Intel 945GC northbridge and ICH7 southbridge, dual‑channel DDRII memory support up to 4 GB, and a range of I/O connectors such as SATAII, USB 2.0, and Realtek 10/100 LAN. Safety warnings, over‑clocking cautions, and BIOS configuration tips are also included.
| Form Factor | Micro ATX (9.6" x 9.0") |
|---|---|
| Supported CPUs | Intel Dual Core, Core 2 Duo, Pentium D, Pentium Dual Core, Pentium 4, Celeron |
| Northbridge Chipset | Intel 945GC A2 |
| Southbridge Chipset | Intel ICH7 |
| Memory Slots | 2 DDRII DIMM slots (Dual Channel) |
| Maximum Memory Capacity | 4 GB |
| SATA Ports | 4 x SATAII 3.0 Gb/s connectors |
| IDE Connector | 1 x ATA100 IDE (supports 2 devices) |
| USB Ports | 4 x USB 2.0 ports (ready‑to‑use) |
| LAN | Realtek PCIE x1 LAN 8101E, 10/100 Mbps |
| Audio Codec | ALC 888 (7.1 CH HD Audio) |
| BIOS | 4 MB AMI BIOS |
The board provides two DDRII DIMM slots.
The motherboard can support up to 4 GB of DDRII memory.
