The IT-3000 Series is a high-speed thermal printer capable of up to 28 lines per second. It comes standard with a C-MOS Imager for scanning 2D/1D symbologies and image capture (M55U models only), as well as a Magnetic Card Reader compatible with ISO7811 for reading data on Tracks 1 and 2 (M54E/M55U models only). This rugged and durable printer is drop tested from 1.2m to concrete and sealed against dust and water to level IP54. It can operate in temperatures from -4°F to 122°F /-20°C to 50°C. The printer features an easy operation with a large, backlit keyboard and offers various industrial standard interfaces for system expansion. It also includes a 3.5-inch (240 x 320 dots) 2-way TFT color LCD for indoor and outdoor use.
The IT-3000 series combines a 3.5‑inch 240 × 320 dot TFT color LCD, back‑lit keyboard and a built‑in thermal printer capable of 28 lines per second. Optional accessories include a C‑MOS imager for 1D/2D barcode capture and a magnetic card reader for secure data entry.
Designed for harsh environments, the terminal meets IP54 dust‑and‑water protection, survives drops from 1.2 m onto concrete and operates from –4 °F to +122 °F (‑20 °C to +50 °C). Connectivity options include Bluetooth 1.1, IrDA, RS‑232C serial ports, an SD memory slot and a PC‑card slot for WLAN or WAN cards, all running on Windows CE .NET 4.1.
| CPU | Intel® PXA255 Application Processor (Max. 400 MHz) |
|---|---|
| RAM | 64 MB |
| Flash ROM | 96 MB (User area approx. 30 MB) |
| Printer speed | 28 lines per second |
| Battery | Lithium‑ion 7.4 V 2200 mAh |
| Operating temperature | -4 °F to +122 °F (‑20 °C to +50 °C) |
| IP rating | IP54 (dust and water‑splash protection) |
| Bluetooth version | 1.1 |
The IT-3000 runs Microsoft Windows CE .NET 4.1.
