U2A is a load cell from Bürkert, Germany. It has a maximum measuring range of 20t and can be used for scales according to OIML R60 standard. It has the characteristics of corrosion resistance, low profile, and easy installation.
The HBM U2A load cell series provides corrosion‑resistant, stainless‑steel measuring bodies for tensile and compressive loads. Capacities range from 50 kg up to 20 t, with an accuracy class of 0.2 and a sensitivity of 2 mV/V. The cells meet EMC requirements (EN 45501) and are available in explosion‑proof versions with IP67 protection.
A variety of mounting accessories are offered, including knuckle eyes (ZGOW, ZGUW) and base plates, with options for extended service temperature up to 120 °C. Technical support and ordering information are provided by HBM in Darmstadt, Germany.
| Maximum capacity | 50 kg to 20 t |
|---|---|
| Accuracy class | 0.2 |
| Sensitivity | 2 mV/V |
| Measuring body material | Stainless steel |
The U2A load cell can handle capacities from 50 kg up to 20 t.
The measuring body is made of stainless steel.
