The REC3.5 series is a 3.5W regulated DC/DC converter with 8kVDC and 10kVDC reinforced isolation. It supports a wide input range of 2:1 and is certified by EN, CSA and CB. It also offers single and dual output options.
The REC3.5 series uses a reinforced isolation transformer to provide high isolation (8 kVDC or 10 kVDC) suitable for industrial and medical applications. It delivers 3.5 W regulated output, continuous short‑circuit protection, and offers two standard DIP‑24 pinout options with optional control pin and undervoltage lockout features.
Key specifications include a 2:1 wide input range, up to 86 % efficiency, 150 mV p‑p output ripple, and compliance with EN, CSA, CB and medical safety standards. The device is packaged in a non‑conductive plastic case, weighs 14 g, and operates from –40 °C to +85 °C.
| Output Power | 3.5 W |
|---|---|
| Input Voltage Range | 2:1 |
| Efficiency | up to 86 % |
| Output Ripple | 150 mV p‑p max |
| No‑Load Power Consumption | 400 mW max |
| Isolation Capacitance | 20 pF typ. |
| Case Material | Non‑Conductive Plastic |
| Operating Temperature Range | -40 °C to +85 °C |
| Package Weight | 14 g |
The converter can achieve up to 86 % efficiency at full load.
It carries EN, CSA and CB certificates and is medically approved.
Output ripple and noise are limited to 150 mV peak‑to‑peak.
