The MAX961-MAX964/MAX997/MAX999 are low-power, ultra-high-speed comparators with internal hysteresis. These devices are optimized for single +3V or +5V operation. The input common-mode range extends 100mV Beyond-the-Rails™, and the outputs can sink or source 4mA to within 0.52V of GND and VCC. Propagation delay is 4.5ns (5mV overdrive), while sup- ply current is 5mA per comparator. The MAX961/MAX963/MAX964 and MAX997 have a shutdown mode in which they consume only 270µA supply current per comparator. The MAX961/MAX963 provide complementary outputs and a latch-enable fea- ture. Latch enable allows the user to hold a valid com- parator output. The MAX999 is available in a tiny SOT23-5 package. The single MAX961/MAX997 and dual MAX962 are available in space-saving 8-pin µMAX packages.
The MAX961‑MAX964/MAX997/MAX999 family are low‑power, ultra‑high‑speed comparators with internal hysteresis, optimized for single‑supply operation at +3 V or +5 V. They feature a Beyond‑the‑Rails input range, 4 mA source/sink capability, and optional latch‑enable functionality.
The document provides detailed electrical characteristics, pin configurations for multiple package types, layout guidelines, and typical performance graphs. It also includes ordering information and mechanical package drawings for SOT‑23, µMAX, SO, and QSOP variants.
| Propagation delay | 4.5 ns |
|---|---|
| Supply current per comparator | 5 mA |
| Output sink/source current | 4 mA |
| Input common‑mode range | 100 mV beyond the rails |
The typical propagation delay is 4.5 ns with a 5 mV overdrive.
Each comparator draws about 5 mA of supply current.
The input common‑mode range extends 100 mV beyond both supply rails.
